XF-20B
直接聯系
常州新馬干燥工程有限公司
江蘇省常州市
5-10萬元
新馬干燥
XF-20B
4319
多種
品質、高效、 節能、環保
食品、醫藥、化工等行業
成都天銀制藥、云南金不換藥業有限公司、貴陽醫學院制藥有限公司、廣元中方、成都利爾、重慶奧力、貴州天方藥業有限公司、南通安惠生物、貴州天方藥業有限公司
XF-20B臥式沸騰干燥機
潔凈的熱風經閥板分配進入床體內，從加料器進入的濕物料被熱風形成流化狀態，如煮沸的開水在床體內跳躍，故稱為沸騰干燥器（或機），由于熱風與物料廣泛接觸，因此在較短的時間內就可以干燥。從床體的一頭進入，經幾分鐘至幾十分鐘時間的“沸騰”，從床體的另一頭自動流出。
Clean hot air enters into fluidization bed through distributor of valve plate. Wet materials comes from feeder will be formed a fluidization state by hot air(jumping within the bed like boiling water), so it is called fluidizing dryer.Because of the large contacting area between hot air and materials, the drying time is very short.The air enters from one end of bed, through “boiling” several minutes, and then comes out automatically from the other end.
沸騰床、旋風分離器及布袋除塵器安放在平整的水泥地平上即可，不需底腳螺絲。風機可安裝在室內或室外，需有底座及地腳螺絲。平面布置可根據廠房情況酌情調整。
風道系統應不漏氣，以免影響干燥效果。
Fluidizing bed, cyclone separator and bag dust remover should be placed on the flat concrete ground, and no foundation screw is needed. The fan with underframe and foundation screws could be installed indoor or outdoors,The plan can be adjusted slightly in accordance with the particle conditions.
No air should leak in air pipe system to be free from the influence on drying efficiency.
